Quik

Features

- Customizable dial plate, front bezel and internal mask
- Dimensions: 230 x 120 x 60 mm
- 2.2" segment LCD
- 2 analog gauges, 1 LED bar graph and 18 telltales + 5 optional
- Antifog treatment
- Power supply: 12 Vdc (9-16 Vdc) and 24 Vdc (18-32 Vdc)
- Protection degree: IP66 front, IP65 rear
- 27 inputs, 1 output (optional) and 1 Vref 5 Vdc output (optional)
- 1 CAN bus interface
- RTC (optional), buzzer
- Connector: Tyco Superseal 34 pins




Quik Plus

Features

- Customizable dial plate, front bezel and internal mask
- Dimensions: 230 x 120 x 60 mm
- 2.7" dot matrix LCD 128 x 128 pixel
- 2 analog gauges and 19 telltales
- Antifog treatment
- Power supply: 12 Vdc (9-16 Vdc) and 24 Vdc (18-32 Vdc)
- Protection degree: IP66 front, IP65 rear
- 27 inputs, 1 output (optional) and 1 Vref 5 Vdc output (optional)
- 1 CAN bus interface
- RTC (optional), buzzer
- Connector: Tyco Superseal 34 pins





Need additional product details? Register and download the Technical Data Sheet.
