- Customizable dial plate, front bezel and internal mask
- Dimensions: Ø 100 mm, external frame Ø 107 mm
- 3.1" dot matrix LCD 160 x 56 pixel
- 18 telltales
- Antifog treatment
- Power supply: 12 Vdc
- Protection degree: IP6K9K front, IP65 rear
- 20 inputs, 1 output (optional)
- 1 CAN bus interface
- RTC (optional), buzzer
- Connector: Tyco Superseal 26 pins

- Customizable dial plate
- Dimensions: Ø 101 mm, external frame Ø 116 mm
- 3,5 ’’ color TFT LCD 320 x 240 pixel with optical bonding
- 2 push buttons (optional) and 5 telltales
- Front glass with anti-glare and anti-reflection treatments
- Power supply: 12 or 24 Vdc
- Protection degree: IP69K front, IP65 rear
- 20 inputs, 1 output
- 1 CAN bus interface
- RTC, buzzer
- Connector: Tyco Superseal 26 pins

Need additional product details? Register and download the Technical Data Sheet.
