Revo Plus

- Customizable dial plate, front bezel and internal mask
- Dimensions: 317 x 152 x 73 mm
- 4.3" color TFT LCD 480 x 272 pixel
- 3 analog gauges (optional 2 or 4 gauges)
- 4 push buttons and 32 telltales
- PMMA front lens with antifog/mineral glass (optional)
- Power supply: 12 Vdc or 24 Vdc
- Protection degree: IP66 front, IP65 rear
- 42 inputs, 4 outputs and 1 Vref 5 Vdc output
- 2 CAN bus interfaces and 1 analog video input
- RTC, buzzer, night & day sensor
- Connectors: 1 Tyco Superseal 34 pins and 1 Tyco Superseal 26 pins

Customizable with

Simulable with
